GS2054HH is an independently engineered 4S2P smart lithium-ion battery platform developed for critical medical devices and life-support systems requiring stable power delivery, intelligent system communication, and high-capacity performance under demanding operating conditions.

The battery delivers a nominal voltage of 14.4V and rated capacity of 6600mAh, providing 95.04Wh of energy while remaining under the 100Wh transportation threshold.

The 4S2P configuration ensures balanced current distribution and extended runtime, supporting continuous operation and high reliability required in life-support and medical-critical applications. Maximum charge voltage is 16.8V with a maximum charge current of 4.83A.

GS2054HH complies with SMBus v1.1 smart battery specifications, enabling host-level communication and runtime monitoring. Integrated fuel gauging supports accurate state-of-charge reporting, while JEITA-based charging optimization enhances temperature-aware charge control.

✅The platform incorporates:

• Panasonic lithium-ion cells for high energy density and stability
• High-precision fuel gauge for accurate battery monitoring
• Cell balancing function to improve lifecycle consistency
• Low internal resistance design for stable output under continuous load

Multiple safety mechanisms include:

• Overcharge, over-discharge, overcurrent, and short circuit protection
• Overtemperature protection with host-monitored temperature capability
• Multiple safety redundancy design for fail-safe operation

The battery maintains up to 80% of initial capacity after 500 cycles, ensuring reliable long-term operation in critical medical environments.

✅ Instrument-Level Integration Checklist

✅ Typical Device Integration Context

GS2054HH is designed for integration into:

• Implantable left ventricular assist devices (LVADs)
• Emergency transport ventilators
• Noninvasive blood flow monitoring systems
• Portable blood transfusion warmers
• Medical tablets and diagnostic terminals
• Industrial-grade data acquisition equipment

The platform supports manufacturers developing life-support systems and high-reliability medical devices requiring continuous operation and stable power delivery

✅ OEM Supply

• No minimum order quantity (MOQ) for standard configuration
• Stock available for immediate or short-cycle delivery
• Typical delivery time: 7–30 days
• Production capacity aligned with standardized battery platform supply

Technical documentation and product specifications are available upon request.

✅ FAQ

Is GS2054HH a 4S2P smart battery pack?

Yes. GS2054HH is a 4S2P lithium-ion battery pack with a 14.4V nominal voltage and 95.04Wh energy rating, designed for high-capacity and critical medical applications.

Does GS2054HH support SMBus communication?

Yes. GS2054HH complies with SMBus v1.1 smart battery specifications, enabling system-level communication, monitoring, and intelligent power management.

Is GS2054HH suitable for life-support systems?

Yes. GS2054HH is designed for critical medical devices including LVAD systems and ventilators, where stable power delivery and safety are essential.

What makes GS2054HH suitable for continuous operation?

The 4S2P configuration provides extended runtime and stable current distribution, supporting continuous operation in high-reliability environments.

What is the production lead time for GS2054HH?

Typical delivery time ranges from 7 to 30 days depending on order volume and scheduling. There is no minimum order quantity restriction.

This battery platform is part of our broader solutions for critical medical and life-support systems requiring high-capacity, stable, and intelligent power management.
